KUHS-225G is designed for all general purpose
applications such as the insulation and the strain relief of
electrical connection and termination , light-duty
Harnessing, jacketing, bundling, and color coding of wires.
Especially, exhibits fire safety characteristics combined with
low smoke emissions and free of Lead(Pb), Mercury(Hg),
Cadmium(Cd), Hexavalent Chrominum(Cr VI),
PBBS(polybrominated Biphenyls), PBDEs(polybrominated Diphenyl
ethers) |
| |
 |
| |
ㆍShrink ratio : 2:1
ㆍMinimum shrink temperature : 90℃
ㆍOperating temperature range : -55℃ to 125℃
ㆍFlammability : UL VW-1 , 600V , 125℃ , except clear
ㆍUL224[REF.] |
| |
 |
| |
ㆍStandard color : Black (*special colors are available upon
request)
ㆍStandard packaging : On spools
ㆍOrdering description : specify product name, size, and
color [ex. KUHS-225G 3.0mm Black] |
| |
 |
| |
| |
Properties |
Test Methods |
Values |
|
Physical |
Unaged |
Tensile strength |
ASTM D-412 |
Min. 1.1kgf/㎟ |
|
Elongation |
UL 224 |
Min. 200% |
|
Aged |
Tensile strength |
ASTM D 412 UL
224 158℃/168hrs |
Min. 0.8kgf/㎟ |
|
Elongation |
Min. 100% |
|
Heat shock |
UL 224 |
Pass@250℃X4hrs |
|
Low temperature flexibility |
ASTM D 2671 |
NO crack@-55℃X4hrs |
|
Secant modulus |
UL 224 |
Max.173MPa |
|
Electrical |
Dielectric strength |
UL 224 |
Min. 2500V/1min |
|
Volume resistivity |
ASTM D 257 |
Min 1X10 ¹⁴Ω-㎝ |
|
Chemical |
Copper corrosion |
UL 224
158℃/168hrs |
No corrosion |
Copper stability
Elongation |
No sign of degradation
Min. 100% |
|
Flammability(VW-1) |
UL 224 |
Pass |
|
| |
 |
| |
|
SIZE |
INSIDE DIAMETER |
WALL THICKNESS |
LENGTH |
FORM |
as
supplied
(AVERAGE) |
after
recovery
(MAX) |
as
supplied
(NOM) |
after
recovery
(MIN) |
| 1.0㎜ |
1.2㎜ |
0.50㎜ |
0.20㎜ |
0.36㎜ |
200ｍ |
Round |
| 1.2㎜ |
1.4㎜ |
0.60㎜ |
0.20㎜ |
0.36㎜ |
200ｍ |
Round |
| 1.5㎜ |
2.0㎜ |
0.75㎜ |
0.20㎜ |
0.44㎜ |
200ｍ |
Round |
| 2.0㎜ |
2.5㎜ |
1.00㎜ |
0.20㎜ |
0.44㎜ |
100ｍ |
Round |
| 2.5㎜ |
3.0㎜ |
1.25㎜ |
0.25㎜ |
0.44㎜ |
100ｍ |
Round |
| 3.0㎜ |
3.4㎜ |
1.50㎜ |
0.25㎜ |
0.44㎜ |
100ｍ |
Round |
| 3.5㎜ |
3.9㎜ |
1.75㎜ |
0.25㎜ |
0.44㎜ |
100ｍ |
Round |
| 4.0㎜ |
4.4㎜ |
2.00㎜ |
0.25㎜ |
0.44㎜ |
100ｍ |
Round |
| 4.5㎜ |
5.0㎜ |
2.25㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 5.0㎜ |
5.6㎜ |
2.50㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 6.0㎜ |
6.5㎜ |
3.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 7.0㎜ |
7.7㎜ |
3.50㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 8.0㎜ |
8.6㎜ |
4.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 9.0㎜ |
9.8㎜ |
4.50㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 10.0㎜ |
10.4㎜ |
5.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 11.0㎜ |
11.4㎜ |
5.50㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 12.0㎜ |
12.5㎜ |
6.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 13.0㎜ |
13.7㎜ |
6.50㎜ |
0.30㎜ |
0.69㎜ |
100ｍ |
Flat |
| 14.0㎜ |
14.4㎜ |
7.00㎜ |
0.30㎜ |
0.69㎜ |
100ｍ |
Flat |
| 15.0㎜ |
15.6㎜ |
7.50㎜ |
0.30㎜ |
0.69㎜ |
100ｍ |
Flat |
| 16.0㎜ |
16.7㎜ |
8.00㎜ |
0.30㎜ |
0.69㎜ |
50ｍ |
Flat |
| 18.0㎜ |
19.3㎜ |
9.00㎜ |
0.35㎜ |
0.77㎜ |
50ｍ |
Flat |
| 20.0㎜ |
21.7㎜ |
10.0㎜ |
0.40㎜ |
0.77㎜ |
50ｍ |
Flat |
| 22.0㎜ |
23.4㎜ |
11.0㎜ |
0.40㎜ |
0.77㎜ |
50ｍ |
Flat |
| 25.0㎜ |
25.5㎜ |
12.5㎜ |
0.45㎜ |
0.87㎜ |
50ｍ |
Flat |
| 28.0㎜ |
29.0㎜ |
14.0㎜ |
0.45㎜ |
0.87㎜ |
50ｍ |
Flat |
| 30.0㎜ |
31.0㎜ |
15.0㎜ |
0.50㎜ |
0.87㎜ |
50ｍ |
Flat |
| 38.0㎜ |
39.0㎜ |
19.0㎜ |
0.50㎜ |
0.97㎜ |
30ｍ |
Flat |
| 50.0㎜ |
51.0㎜ |
25.0㎜ |
0.50㎜ |
0.97㎜ |
30ｍ |
Flat |
| 75.0mm |
80.0mm |
41.0mm |
0.70mm |
1.46mm |
25m |
Flat |
| 100.0mm |
100.0mm |
51.0mm |
|
|
|
|
| 3/64inch |
1.4㎜ |
0.60㎜ |
0.20㎜ |
0.36㎜ |
200ｍ |
Round |
| 1/16inch |
2.0㎜ |
0.75㎜ |
0.20㎜ |
0.44㎜ |
200ｍ |
Round |
| 3/32inch |
2.5㎜ |
1.00㎜ |
0.20㎜ |
0.44㎜ |
100ｍ |
Round |
| 1/8inch |
3.4㎜ |
1.50㎜ |
0.25㎜ |
0.44㎜ |
100ｍ |
Round |
| 3/16inch |
5.0㎜ |
2.25㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 1/4inch |
6.5㎜ |
3.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 3/8inch |
9.8㎜ |
4.50㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Round |
| 1/2inch |
12.5㎜ |
6.00㎜ |
0.25㎜ |
0.56㎜ |
100ｍ |
Flat |
| 3/4inch |
19.3㎜ |
9.00㎜ |
0.35㎜ |
0.77㎜ |
50ｍ |
Flat |
| 1inch |
25.5㎜ |
12.5㎜ |
0.40㎜ |
0.87㎜ |
50ｍ |
Flat |
| 11/2inch |
39.0㎜ |
19.0㎜ |
0.50㎜ |
0.97㎜ |
30ｍ |
Flat |
| 2inch |
51.0㎜ |
25.0㎜ |
0.50㎜ |
0.97㎜ |
30ｍ |
Flat |
ㆍ Special order size are available upon
request
ㆍ Wall thickness will be less if tubing recovery is
restricted during shrinkage |
|
 |
| |
|
|
|
|
