UNI-EIT is a flexible, flame-retardant Polyolefin
tubing
these are widely used for insulating and protective covering for
wires. |
| |
 |
| |
ㆍOperating temperature range : -55℃ to 125℃
ㆍFlammability : UL VW-1 , 600V , 125℃ , except clear
ㆍUL224[REF.] |
| |
 |
| |
ㆍStandard color : Black (*special colors are available upon
request)
ㆍStandard packaging : On Reels (*on spools are available upon request)
ㆍOrdering description : specify product name, size, and color
[ex. UNI-EIT 3.0mm Black] |
| |
 |
| |
| |
Properties |
Test Methods |
Values |
|
Physical |
Unaged |
Tensile strength |
ASTM D 412 |
Min. 1.1kgf/㎟ |
|
Elongation |
UL 224 |
Min. 200% |
|
Aged |
Tensile strength |
ASTM D 412 UL
224 158℃/168hrs |
Min. 0.8kgf/㎟ |
|
Elongation |
Min. 100% |
|
Heat shock |
UL 224 |
Pass@250℃X4hrs |
|
Low temperature flexibility |
ASTM D 2671 |
NO crack@-55℃X4hrs |
|
Secant modulus |
UL 224 |
Max.173MPa |
|
Electrical |
Dielectric strength |
UL 224 |
Min. 2500V/1min |
|
Volume resistivity |
ASTM D 267 |
Min 1X10¹⁴Ω-㎝ |
|
Chemical |
Copper corrosion |
UL 224
158℃/168hrs |
No corrosion |
Copper stability
Elongation |
No sign of degradation
Min. 100% |
|
Flammability(VW-1) |
UL 224 |
Pass |
|
| |
 |
| |
| SIZE |
D(mm)
Insider dia.
(NOM) |
T(mm)
Thickness
(NOM) |
D'(mm)
Out dia.
(NOM) |
STANDARD
Spool
Length
(M) |
| 3.0㎜ |
3.0㎜ |
0.35㎜ |
3.70㎜ |
200ｍ |
| 5.0㎜ |
5.0㎜ |
0.35㎜ |
5.70㎜ |
100ｍ |
| 6.0㎜ |
6.0㎜ |
0.35㎜ |
6.70㎜ |
100ｍ |
| 8.0㎜ |
8.0㎜ |
0.40㎜ |
8.80㎜ |
100ｍ |
| 9.0㎜ |
9.0㎜ |
0.40㎜ |
9.80㎜ |
100ｍ |
| 10.0㎜ |
10.0㎜ |
0.40㎜ |
10.80㎜ |
100ｍ |
| 11.0㎜ |
11.0㎜ |
0.40㎜ |
11.80㎜ |
100ｍ |
| 12.0㎜ |
12.0㎜ |
0.40㎜ |
12.80㎜ |
100ｍ |
| 13.0㎜ |
13.0㎜ |
0.50㎜ |
14.00㎜ |
100ｍ |
| 14.0㎜ |
14.0㎜ |
0.60㎜ |
15.20㎜ |
100ｍ |
| 16.0㎜ |
16.0㎜ |
0.80㎜ |
17.60㎜ |
100ｍ |
| 18.0㎜ |
18.0㎜ |
0.90㎜ |
19.80㎜ |
50ｍ |
| 22.0㎜ |
22.0㎜ |
1.20㎜ |
24.40㎜ |
50ｍ |
| 25.0㎜ |
25.0㎜ |
1.50㎜ |
28.00㎜ |
50ｍ |
ㆍ Special order size are aveilable upon
request
ㆍ Wall thickness will be less if tubing recovery is
restricted during shrinkage |
|
 |
| |
|
